Cutting Control System |
X I Y DC Servo motor |
|
|
Positioning Sensor Type |
Digital camera (CCD) |
|
|
Control panel |
4.3 inch capacitive touch screen |
|
|
Number of tool holders |
Double tool holders |
|
|
Blade types |
Blade, creasing tool and pen |
|
|
Cutting precision (Patterns) |
Three patterns (Speed first, Balance first, Precision first) |
|
|
Sheet feeding method |
Friction feed |
|
|
Sheet feeding |
Up to 20mm ( about 7 00 sheets of self – adhesive material) |
|
|
Scanning code type |
Round marker, corner marker, QR code |
|
|
Maximum paper feed size |
483mmX330mm |
|
|
Maximum cutting size |
330mmX483m |
|
|
Scanning speed |
About 5s |
|
|
Cutting speed |
10-1200 |
|
|
Maximum paper weight |
250g(Depend on varaible material) |
|
|
Minimum cutting character |
About 5mm |
|
|
Mechanical resolution |
0.02mm |
|
|
Programmable Resolution |
HPGL 0.025mm |
|
|
Repeat precision |
≤0.05mm |
|
SOFTWARE AND COMPATIBILITY
|
Connectivity |
USB, WLAN, WiFi, U disk |
|
|
Software and Compatibility |
Cutstudio，Corel Draw / Illustrator Plugin |
|
POWER AND WORKING ENVIRONMENT REQUIREMENTS
|
Working Power |
Maximum 150W |
|
|
Voltage and current |
100VAC ~ 240VAC,50/60Hz,Maximum current4A |
|
|
Operation environment |
Temperature +5°C to +35°C(Fahrenheit 41-95), Humidity 30% -75% (Non-condensing) |
|
