Model |
A-6202/ 6203/ 6204 |
||
|
Print Head |
2/3/4 Print Heads Optional (i3200-A 1) |
||
|
Acceptable Media |
Width: 620 mm Thickness: Maximum 39 miI(1 mm) |
||
|
Printing Width |
600 mm |
||
|
Ink Cartridges |
Type: Transfer Pigment Ink Capacity : Continual Ink Supply System ( 220ML ) Color : CMYK+W / CMYKFyFm + W(3H) |
||
|
Applicable Medium |
Transfer film |
||
|
Color Manage |
ICC or density curve |
||
|
Media Heating System |
Powder & color fixing machine |
||
|
Interface |
RJ-45/LAN |
||
|
RIP Software |
Main top |
||
|
Power Supply |
50HZ/60HZ,220V/11 0V/1 QA |
||
|
Environment |
Temperature: 10°C to 38°C Humidity: 40% to 70% |
||
|
Printer Dimensions |
L 1620mm*W620mm*H 1590mm (With Stand) |
||
|
Packing Dimensions |
L 1700mm*W750MM*H760mm |
||
|
Weight |
G.W: 230kg N.W :180kg |
||
|
Model |
SHAKING POWDER AND COLOR FIX MACHINE |
||
|
Media Width |
0-60CM I 0-80CM |
||
|
Applicable Medium |
Nylon, Chemical Fiber, Cotton, Leather, Swimwear, Wetsuit, PVC, EVA, etc. |
||
|
Powder Control |
Powder shake control, powder control, powder direction & volume control |
||
|
Heating & Drying Function |
Multi-stage heating system, drying, cold air fan function |
||
|
Rewind Function |
Automatic induction winding |
||
|
Electrical Parameters |
Rated Voltage: 220V I Rated Current: 30A Rated Power: 6.6KW I Power Consumption: 2.2 KWh-5KWh |
||
|
Powder Shaker Size |
60cm·1780*980*1040mm I 80cm·1780*1180*1040mm 60cm.1780″1100″1040mm (Built-in smoke filter) I 80cm.1780*1100″1040mm (Built-in smoke filter) |
||
|
Weight |
N.W.210kg I N.W.220kg |
||
*Specifications are subject to change without prior notice, all rights reserved.
