Laser Mode |
80W CO2 Laser + 5W IR Laser (Optional) |
|
|
Processing Mode |
Laser Cutting Laser Engraving |
|
|
Supported Materials |
Laser Cuttable: Wood, Acrylic, Fabric, Leather and more Laser Engravable: Metal, Glass, Bamboo,Ceramic and more |
|
|
Working Area |
36″ x 18″ (915 mm x 458 mm) |
|
|
Max. Working Speed |
47.2 ips (1200 mm/s), X-axis Acceleration 19600 mm/s² |
|
|
Max. Laser Cutting Capacity (Basswood) |
0.79″ (20 mm) in ONE PASS |
|
|
Max. Laser Cutting Capacity (Acrylic) |
0.98″ (25 mm) in ONE PASS |
|
|
Max. Processing Height |
8.66″ (220 mm) |
|
|
Max. Rotary Engraving Diameter |
0 – 7.87″ (0 – 200 mm) |
|
|
Supported Software |
xTool Studio |
|
|
Operating System |
Windows/MacOS |
|
|
Connection Method |
USB/Wi-Fi |
|
|
Supported Files |
SVG/DXF/JPG/JPEG/PNG/BMP/TIF |
|
|
Almake Compatibility |
Yes |
|
|
Easy Operation |
Yes |
|
|
ACS™ (Automated Creation System™) |
Yes |
|
|
Built-in Camera |
16 MP SkyView Panoramic Camera + Close-range Camera + Side Camera × 2 |
|
|
Positioning Method |
Dual-Camera Positioning |
|
|
Focus Mode |
Autofocus |
|
|
Ranging System |
LiDAR Ranging System |
|
|
Preview Method |
Smart Camera Preview |
|
|
Laser Spot Size |
S Focal Lens: 0.0055″ × 0.0063″ (0.14 mm × 0.16 mm) (optional) M Focal Lens: 0.0059″ × 0.0071″ (0.15 mm × 0.18 mm) (standard) L Focal Lens: 0.0071″ × 0.0079″ (0.18 mm × 0.20 mm) (optional) |
|
|
Positioning Precision |
0.0079″ (0.2 mm), Camera |
|
|
Motion Accuracy |
0.00039″ (0.01 mm) |
|
|
Safety Certification |
Class 1 Laser Safety |
|
|
Product Dimensions |
49.2″ × 30.7″ × 19.5″ (1250 mm × 780 mm × 496 mm) |
|
|
Product Weight |
231.5 lb (105 kg) |
|
|
Max. Machine Input Power |
1400 W |
|
|
Power Adapter Input Voltage |
100 V – 240 V, AC 50/60 Hz |
|
