Laser Type |
5W 355 nm UV Laser |
|
|
Processing Mode |
Laser Engraving Laser Cutting |
|
|
Supported Materials |
Laser Engravable: Glass, Crystal, Acrylic, Wood, Metal, Leather, Plastic, Rubber, Silicone, Ceramic and more Laser Cuttable: Glass, Plastics (PE, PP, EVA, PET, etc.), Fabric, Leather, Acrylic (Not Fully Transparent), Paper, Wood, and More |
|
|
Working Area |
Inner Engraving: 2.8″ × 2.8″ (70 mm × 70 mm) Surface Engraving: 7.9″ × 7.9″ (200 mm × 200 mm) Surface Engraving with Conveyor: 7.9″ × 19.7″ (200 mm × 500 mm) |
|
|
Max. Working Speed |
590.55 ips (15,000 mm/s) |
|
|
Max. Laser Cutting Capacity (Basswood) |
0.59″ (15 mm) in Multiple Passes |
|
|
Max. Laser Cutting Capacity (Acrylic) |
0.47” (12 mm) in Multiple Passes |
|
|
Max. Processing Height |
5.9” (150 mm) |
|
|
Max. Rotary Engraving Diameter |
5.9” (150 mm) |
|
|
Supported Software |
xTool Studio |
|
|
Operating System |
Windows/macOS |
|
|
Connection Method |
USB/Wi-Fi/IP |
|
|
Supported Files |
2D: SVG, DXF, JPG, JPEG, GIF, PNG, BMP, and WEBP 3D: STL, OBJ, AMF, 3MF, GLB, PLY |
|
|
AImake Compatibility |
Yes |
|
|
Pre-assembled |
Yes |
|
|
Built-in Camera |
48 MP Dual Cameras |
|
|
Positioning Method |
Camera Positioning |
|
|
Focus Mode |
Autofocus |
|
|
Ranging System |
LiDAR Ranging System |
|
|
Preview Method |
Smart Camera Preview High-speed Light Live Preview |
|
|
Laser Spot Size |
0.02 × 0.02 mm |
|
|
Positioning Accuracy |
0.0079″ (0.2 mm), Camera |
|
|
Ranging Accuracy |
0.0079″ (0.2 mm), Camera |
|
|
Image Resolution |
48 MP |
|
|
Motion Resolution |
0.00005” (0.00133 mm) (Inner Engraving) |
|
|
Vector Fitting Resolution |
0.00004” (0.001 mm) |
|
|
Safety Certification |
Class 4 Laser Safety |
|
|
Machine Dimensions |
11.6” × 16.9” × 20.5” (294 mm × 429 mm × 520 mm) |
|
|
Machine Weight |
49.6 lb (22.5 kg) |
|
|
Max. Machine Input Power |
348W |
|
|
Power Adapter Input Voltage |
110 V – 240 V, AC 50/60 Hz |
|
|
Storage Temperature Range |
-10 to 60°C (14 to 140°F) |
|
|
Operating Temperature Range |
10 to 30°C (50 to 86°F) |
|
|
Storage Humidity |
10 – 60% Rh |
|
