Maximum Cutting Width |
700mm |
|
|
Cutting Speed |
Gear adjustment 1-5 |
|
|
Cutting Method |
Double Round Knife |
|
|
Positioning Mode |
Camera |
|
|
Blade Materials |
High Speed Steel |
|
|
Service Life of Blades |
More than 50,000 times+ (Conventional Materials) |
|
|
Cutting Materials |
DTF Film and Other Materials |
|
|
Working Mode |
Automatic Mode: identify the marking line & cut it automatically Fixed Length Mode: Set a Fixed length for automatic cutting |
|
|
Slitting Function |
Automatic Slitting Correction in the Feed Direction (5 Slitting Knives as standard) |
|
|
Starting Mode |
Press the Button to Start |
|
|
Control Panel |
LCD Blue Screen with Buttons |
|
|
Motor Type |
DC Servo Motor |
|
|
Maximum Material Thickness |
0.5mm |
|
|
Actual Dimensions |
L 1320mm x W 424mm X H 282mm |
|
|
Package Dimensions |
L 1618mm x W 608mm x H 615mm |
|
POWER AND WORKING ENVIRONMENT REQUIREMENTS
|
Working Voltages and Current |
100VAC～120VAC, 50/60 Hz, Maximum Current 6.8A 200VAC～240VAC, 50/60 Hz, Maximum Current 3.4A |
|
|
Power |
350W |
|
|
Operation Environment |
Temperature +5°C to +35°C (Fahrenheit 41-95), Humidity 35% -70% (Non-condensing) |
|
