Maximum Sheet Size |
1800mm |
|
|
Maximum Cutting Size |
1695mm |
|
|
Minimum Cutting Character |
About 5mm2 |
|
|
Mechanical Resolution |
0.02mm |
|
|
Repeat Precision |
0.082mm |
|
|
Maximum Linear Cutting Speed |
960mm/s |
|
|
Maximum Cutting Force |
750g |
|
|
Cutting Control System |
DC Servo |
|
|
Motor Speed |
0-3000RPM |
|
|
CPU |
64-DSP |
|
|
Package Dimensions |
L2100mm x W400mm x H550mm |
|
|
Actual dimensions |
L1960mm x W250mm x H260mm |
|
|
Gross/ Net Weight |
68±10Kg/47±10Kg |
|
|
Connectivity |
USB/ LAN/ U_disk |
|
|
Software and Compatibility |
Dragon Cut for Computer, Compatible for Windows 7, 8, 10 Corel Draw/ Illustrator Plug-In |
|
POWER AND WORKING ENVIRONMENT REQUIREMENTS
|
Power Source |
100V~240v, 50/60Hz |
|
|
Power |
150W |
|
|
Operation Environment |
Temperature +5°C to +35°C(Fahrenheit 41-95), Humidity 30% -75% (Non-condensing) |
|
|
Stand and Pocket |
Included |
|
