Working Motor |
X-servo motor Y-Servo Motor |
|
|
Positioning Sensor Type |
CCD Camera |
|
|
Control Panel |
7 inch capacitive touch screen |
|
|
Number of Tool Holders |
Single cartridge |
|
|
Blade Types |
Graver/pen/wheel indentation (back indentation) |
|
MACHINE PERFORMANCE
|
New Features |
Material Back Indentation |
|
|
Media Hold Method |
Vacuum Adsorption |
|
|
Scanning Code Type |
Mark or QR Code |
|
|
Cutting Size |
Max: X:530mm Y:740mm I Min: X:297mm Y:420mm |
|
|
Sheet feeding |
About 95mm |
|
|
Scanning Speed |
About 5s |
|
|
Cutting Speed |
15-1050 |
|
|
Cutting Force |
Creasing：0-2500gf Blade：0-900gf |
|
|
Maximum Weight of Paper |
250g-400g (varies for di erent cutting materials) |
|
|
Minimum Cut Character Size |
About 10 mm2 (varies depending font graphics & cutting material) |
|
|
Internal Storage Space |
Memory size: 128M I Function: For storing cutting files use |
|
|
Mechanical Resolution |
0.02mm |
|
|
Programmable Resolution |
HPGL 0.025mm |
|
|
Repeat Precision |
≤0.05mm |
|
|
Cutting Media Types |
Card Stock |
|
SOFTWARE AND COMPATIBILITY
|
Connectivity |
USB / U disk/ WLAN / WiFi |
|
|
Software and Compatibility |
CutArtist software、CorelDRAW /lllustrator Plug-in |
|
POWER AND WORKING ENVIRONMENT REQUIREMENTS
|
Power |
Max 600W |
|
|
Voltage |
00VAC至240VAC,50/60Hz |
|
|
Operation environment |
Temperature +5°C to +35°CI Humidity 30% -75% (Non-condensing) |
|
Dimensions and Weight
|
Machine Dimensions |
1110X860X1200mm |
|
*Specifications are subject to change without prior notice, all rights reserved.
