Model |
MXC-R5310 V9 |
|
Max Cutting Size (mm) |
530×560 |
|
Max Cutting Thickness (mm) |
100 |
|
Min Pushing Size(mm) |
20 |
|
Position Accuracy |
+/- 0.1 |
|
Cutting Accuracy |
+/- 0.2 |
|
Ball Table |
✓ |
|
Pressing |
Hydraulic + Foot |
|
Cutting |
Hydraulic |
|
Touch Screen |
10.2″ Touch Screen |
|
Programs |
✓ |
|
Four-Rule Operation |
✓ |
|
Automatic Measurement |
✓ |
|
Pushing Motor |
HIgh SPeedd Stepper Motor |
|
Pushing Speed |
7m/ Min |
|
Voltage |
220V(110V)+/-10%50Hz(60Hz)/ Min |
|
Power |
2200w |
|
Side Table |
Option |
|
Dimension (mm) |
1250 * 900 * 1400 |
|
N.W (Kg) |
500 |
*Specifications are subject to change without prior notice, all rights reserved.
