Model |
Working Size |
Type |
|
|
XT-1625 |
1600 X 2500 X 55 MM |
Converyor |
|
|
XT-2530 |
2500 X 3000 X 55 MM |
Converyor |
|
|
XT-2540 |
2500 X 4000 X 55 MM |
Converyor |
|
|
XT-3225 |
3200 X 2500 X 55 MM |
Converyor |
|
|
XT-3230 |
3200 X 3000 X 55 MM |
Converyor |
|
*Sizes and Features are subject to change without prior notice, all rights reserved.
|
Model |
XT-1625 |
|
|
Effective Cutting Area |
1600 X 2500 mm |
|
|
Air Pump Power |
7.5KW |
|
|
Total Power |
9.5KW |
|
|
Cutting Speed |
300-1800mm/s (according to different materials) |
|
|
Cutting Thickness |
≤ 50mm (according to different materials) |
|
|
Working Environment |
Temperature: 0°C-35°C I Humidity:35%-80% |
|
|
Transmisson System |
High-end servo motor drive,imported liner guides |
|
|
Working voltage/Power |
AC 380V±10% 3-Phase/AC 220V ± 10% 3-Phase 50Hz/60Hz |
|
|
File system |
Compatible with HPGU/ PLT/ DXF etc. |
|
|
Transmission Port |
Standard nerwork Port |
|
|
Fixed Method |
Vacuum adsorption |
|
|
Operation Interface |
Machine Control Unit |
|
|
Feeding Method |
Imported crawler automatic feeding method (can be cut in umlimited length) |
|
|
Standard Tools |
High Speed Oscillating Tool, Universal Cutting Tool, CCD automatic possitioning system cursor, AKI |
|
|
Optional Tools |
Pen, V-Cut, Creasing Wheel, Milling Tool Ser, 50mm Foam Cutting Tool, Kiss Cut Tool |
|
*Specifications are subject to change without prior notice, all rights reserved.
